Use Menu to manage MDI Children Window
Use Menu to manage MDI Children Window

Imports System
Imports System.Collections
Imports System.Data
Imports System.IO
Imports System.Xml.Serialization
Imports System.Windows.Forms
Imports System.Drawing
Imports System.Drawing.Drawing2D
Imports System.Drawing.Text
Imports System.Drawing.Printing


Public Class MainClass
    Shared Sub Main()
       Dim form1 As Form = New Form1()
       Application.Run(form1
     End Sub
End Class








Public Class Form1
    Inherits System.Windows.Forms.Form

#Region " Windows Form Designer generated code "

    Public Sub New()
        MyBase.New()

        'This call is required by the Windows Form Designer.
        InitializeComponent()

        'Add any initialization after the InitializeComponent() call

    End Sub

    'Form overrides dispose to clean up the component list.
    Protected Overloads Overrides Sub Dispose(ByVal disposing As Boolean)
        If disposing Then
            If Not (components Is NothingThen
                components.Dispose()
            End If
        End If
        MyBase.Dispose(disposing)
    End Sub
    Friend WithEvents MainMenu1 As System.Windows.Forms.MainMenu
    Friend WithEvents mnuExit As System.Windows.Forms.MenuItem
    Friend WithEvents mnuFile As System.Windows.Forms.MenuItem
    Friend WithEvents mnuNew As System.Windows.Forms.MenuItem

    'Required by the Windows Form Designer
    Private components As System.ComponentModel.Container

    'NOTE: The following procedure is required by the Windows Form Designer
    'It can be modified using the Windows Form Designer.
    'Do not modify it using the code editor.
    <System.Diagnostics.DebuggerStepThrough()Private Sub InitializeComponent()
        Me.MainMenu1 = New System.Windows.Forms.MainMenu()
        Me.mnuFile = New System.Windows.Forms.MenuItem()
        Me.mnuNew = New System.Windows.Forms.MenuItem()
        Me.mnuExit = New System.Windows.Forms.MenuItem()
        '
        'MainMenu1
        '
        Me.MainMenu1.MenuItems.AddRange(New System.Windows.Forms.MenuItem() {Me.mnuFile})
        '
        'mnuFile
        '
        Me.mnuFile.Index = 0
        Me.mnuFile.MenuItems.AddRange(New System.Windows.Forms.MenuItem() {Me.mnuNew, Me.mnuExit})
        Me.mnuFile.Text = "File"
        '
        'mnuNew
        '
        Me.mnuNew.Index = 0
        Me.mnuNew.Text = "New"
        '
        'mnuExit
        '
        Me.mnuExit.Index = 1
        Me.mnuExit.Text = "Exit"
        '
        'Form1
        '
        Me.AutoScaleBaseSize = New System.Drawing.Size(615)
        Me.ClientSize = New System.Drawing.Size(292272)
        Me.Menu = Me.MainMenu1
        Me.Name = "Form1"
        Me.Text = "MDI Example 2"

    End Sub

#End Region

    Private Sub Form1_Load(ByVal sender As System.Object, _
  ByVal e As System.EventArgs_
  Handles MyBase.Load
        Me.Text = "I'm an MDI Parent"
        Me.IsMdiContainer = True
        Dim MyChild As New System.Windows.Forms.Form()
        MyChild.MdiParent = Me
        MyChild.Show()
        MyChild.Text = "First MDI Child"
        InitializeMenu()
    End Sub
    Public Sub InitializeMenu()
        Dim mnuWindow As New MenuItem("&Window")
        MainMenu1.MenuItems.Add(mnuWindow)
        mnuWindow.MenuItems.Add(New MenuItem("&Cascade", AddressOf WindowCascade_Clicked))
        mnuWindow.MenuItems.Add(New MenuItem("Tile &Horizontal", AddressOf WindowTileHoriz_Clicked))
        mnuWindow.MenuItems.Add(New MenuItem("Tile &Vertical", AddressOf WindowTileVert_Clicked))
        mnuWindow.MdiList = True
    End Sub

    Protected Sub WindowCascade_Clicked(ByVal Sender As Object, _
      ByVal e As System.EventArgs)
        Me.LayoutMdi(MdiLayout.Cascade)
    End Sub

    Protected Sub WindowTileHoriz_Clicked(ByVal Sender As Object, _
      ByVal e As System.EventArgs)
        Me.LayoutMdi(MdiLayout.TileHorizontal)
    End Sub

    Protected Sub WindowTileVert_Clicked(ByVal Sender As Object, _
      ByVal e As System.EventArgs)
        Me.LayoutMdi(MdiLayout.TileVertical)
    End Sub

    Private Sub mnuExit_Click(ByVal sender As System.Object, ByVal e As System.EventArgsHandles mnuExit.Click
        System.Environment.Exit(0)
    End Sub


    Private Sub mnuNew_Click(ByVal sender As System.Object, ByVal e As System.EventArgsHandles mnuNew.Click
        Static numOfChildren As Integer = 2
        Dim MyChild As New System.Windows.Forms.Form()
        MyChild.MdiParent = Me
        MyChild.Show()
        MyChild.Text = "MDI Child " & CStr(numOfChildren)
        numOfChildren += 1
    End Sub
End Class
